Online Workshop On Switch mODE PSU Design

In partnership with Texas Instruments and Würth Elektronik:

Online PSU Design Workshop

Prefer the in-person classroom format? Click here

If you need to get up to speed with power supply design fast, then this workshop is for you.

Learn to design power supplies online from ground up with Dr Ali Shirsavar in this unique online course. Delivered as an online, self-paced course, it teaches a structured and repeatable methodology for designing real power supplies, from initial specifications through to complete component selection and documentation. Unlike many university courses, this workshop focuses on practical hardware design skills that can be applied directly to product development projects for practicing engineers new to power supply design. An in-person, hands-on version of this workshop is also available. Click here for details.

Using numerous bite-sized videos recorded by Ali himself as well as presentations, end-of-chapter quizzes, and design examples, each participant will learn how to design and select each component until the power supply design is complete. By the end of the workshop, you will have designed a complete and fully functioning power supply, with all component specified down and selected. You will have the tools and methods needed to repeat the design process for other power supply specifications.

The design methods and engineering principles learned are directly transferable to all other DC-DC power supplies, and a detailed Buck example is given. In addition, all participants will receive a free license* for our advanced Power Supply Design Software WDS capable of designing most hard-switched power supply topologies.

This workshop will take approximately 40 full-time hours to complete and counts toward your Continuing Professional Development (CPD). Upon completion, you will receive a certificate for your personal development file, recognizing your achievement in power supply design.

These workshops are designed for electronic engineers who:

• Are involved in the design, review, or specification of power supplies
• Need to rapidly get up to speed with power supply design for real projects
• Want practical experience translating datasheet parameters into real design decisions
• Want confidence in component selection with appropriate safety margins for production ready power supplies
• Need to add a minimum of 40 hours of continuous professional development hours to their portfolio
• Wish to become a specialist in power supply design

Workshop Outline

• ​​​DC-DC Converter Basics
  • Switching Power Supply Operation
  • Overview of the Buck converter operation and all of its components that we will design
  • Optional hands-on Lab (Add-on)
• Inductor Selection
  • Operation of the inductor in our power supply
  • Conduction modes
  • All inductor parameters needed for section (inductance, rated current, saturation current magnetic material)
  • Using free online tools to narrow down and select your inductor quickly
  • Real-life design example: inductor selection down to part number
  • Optional hands-on Lab (Add-on)
• Switching Strategies
  • Asynchronous switching, synchronous switching, synchronous with diode emulation
  • Which switching strategy is most suitable for your application
  • Correct PWM IC selection for your application
  • Optional hands-on Lab (Add-on)
• MOSFET Selection
  • MOSFET selection without switching loss calculations
  • MOSFET selection with switching loss calculation
  • How to read the device datasheet and extract the parameters that you need
  • Gate resistor calculations and selection
  • Using free online tools to narrow down and select your MOSFET quickly
  • Real-life design example 1: MOSFET selection down to part number, without switching loss calculation for a low to medium power converters
  • Real-life design example 2: MOSFET selection down to part number, with switching loss calculation for medium to high power converters
  • Optional hands-on Lab (Add-on)
• Diode Selection
  • Power diode types, parameters and selection
  • How read the datasheet and extract the parameters that you need
  • Using free online tools to narrow down and select your power diode quickly
  • Real-life design example: Power diode selection down to component part number
  • Optional hands-on Lab (Add-on)
• Output Capacitor Selection
  • Why do we need Output capacitance?
  • Output ripple and noise reduction
  • Output bulk capacitor selection
  • Output capacitor calculations and selection
  • Extracting capacitor ESR information for control loop design
  • Using free online tools to narrow down and select your capacitors quickly
  • Real-life design example: Output capacitor selection down to component part number
  • Optional hands-on Lab (Add-on)
• Beginner Friendly, Step-by-Step Control Loop Design
  • All that you need to know for fast control loop parameter calculation
  • Control mode selection for your power (voltage mode, voltage mode with input voltage feedforward, current mode, constant-on-time)
  • What are Bode plots and how to read and use them for stability
  • Using various software tools to design control loops and calculate components quickly
  • Real-life control loop design example down to component part number
  • Optional hands-on Lab (Add-on)
• Input Capacitor Selection
  • Why do we need input capacitance?
  • Input ripple and noise reduction capacitance selection
  • Input bulk capacitor selection
  • Using free online tools to narrow down and select your capacitors quickly
  • Real-life design example 1: Ceramic input capacitor selection down to component part number
  • Real-life design example 2: Electrolytic input capacitor selection down to component part number
  • Optional hands-on Lab (Add-on)
• All Other Necessary Components
  • Current sense circuit design and over-current protection
  • Soft start components selection
  • Clock components selection
  • Sizing bypass capacitance
  • Optional hands-on Lab (Add-on)

Optional Hands-On Labs (Add-On)

For participants who wish to gain hands-on practical experience, optional hands-on labs are available as a companion to the workshop. These extra labs are not required for completion of the workshop and are provided purely to enhance the learning experience. They follow a complete Asynchronous Buck converter design example from specification to component selection and include self-guided laboratory exercises using a dedicated learning board from Würth Elektronik.

To work through these optional labs, you will need access to an oscilloscope (with a bandwidth of better than 50MHz), a soldering iron, the Würth Elektronik Buck Converter Learning Kit (part number 988113), a small 12 V, 10 W power supply, and suitable resistive loads. Full instructions will be provided upon registration.

The Würth Elektronik learning board referenced in the optional labs is provided separately by Würth Elektronik and may not always be immediately available for purchase. This does not affect participation in or completion of the workshop, and the hands on exercises may be carried out when the hardware becomes available.

Pricing

Completion

Following the completion of the workshop, users will receive a certificate. You must complete the entire online workshop to receive your certificate. This workshop will constitute 40 hours of CPD (Continuing Professional Development)

Prerequisites

The audience must have a degree in electrical/electronic engineering, computer science or equivalent.
These workshops are highly technical, intended for professional engineers and are not suitable for the general public without relevant qualifications.

* 18 month access to the course material plus 18 months license for Biricha WDS. You must have unrestricted access to the internet. You will have 18-months to complete the workshop. After this time you can extend your registration on a monthly basis for a small fee.
